Inconel Blind Flange
- sales@shikharsteel.com
Sizes in Stock
1/2" to 24"
Sizes Can Be
Manufacture
Up to DN1600
Grades
Inconel 600, 601, 625, 686,
718, 725, X750
Types of Steel
Nickel Chromium Based Superalloys
Known for
High Temperature Stability
UNS Designation
UNS N06600, UNS N06601,
UNS N06625, UNS N07718
Designed to
Withstand Extreme Conditions
Environments
Sea Water and Neutral Salts
Table Of Content
Shikhar steel is a leading Inconel flanges manufacturer in India with an IBR & ISO certification in India. We produce the Inconel 625 Blind Flanges in DN15 to DN1200 sizes and pressure class 150 to 2500. We are experts in manufacturing customized Inconel blind flange as per client drawing.
Factors to Consider When Choosing Inconel Flanges for Oil & Gas Plant in Nigeria and Spain
Inconel Flanges Specification
Manufacturing Size Range
Pressure Class of Inconel Pipe Flange
Faces of Inconel Blind Flange
Standard of Inconel Forged Flange
Manufacturing Process of Inconel Steel Flange
Thickness of Inconel Weld Flange
Process of Inconel Forgings Flange
Threads of Inconel 625 Threaded Flange
Surface Finish of Inconel 625 Flanges
Bolts Hole of Alloy 625 Flange
Application of Inconel 625 Blind Flanges
Packaging of Inconel 625 Slip On Flanges
Suitable Environment of Inconel 625 Weld Neck Flanges
Testing for Inconel 600 Flanges
Connection of Inconel 600 Pipe Flange
Inconel 718 Flanges European Standard
Logistics of ASTM B564 UNS N06600 Flange
Origin of ASTM B564 UNS N06625 Forgings
B564 UNS N06601 Flanges German Standard
UNS N07718 Flange Japanese Standard
Shikhar steel is one of the leading Inconel flanges manufacturer in India, We are IBR certified and best quality product supplier of Inconel 600 slip on flanges in india. The resistance of the Inconel 625 flange to various oxidising substances like nitric acid and oxidising salt.
Inconel Flanges Grade
As a Indian leading Inconel flanges manufacturer in India, Shikhar steel corporation produces Inconel 625 flanges in various sizes and wall thickness, ASTM B564 UNS N06600 flange have excellent fabricability, high strength and outstanding corrosion resistance.
Inconel 625 Flanges Pressure Rating
| Temperature | Class 300 Inconel Flange (Bar) | Class 150 Inconel Flange (Bar) |
|---|---|---|
| 700°C | 8.8 | - |
| 675°C | 11.5 | - |
| 650°C | 14.1 | - |
| 600°C | 21.6 | - |
| 550°C | 25.0 | - |
| 500°C | 28.2 | 2.8 |
| 450°C | 33.7 | 4.6 |
| 400°C | 36.5 | 6.5 |
| 350°C | 40.3 | 8.4 |
| 300°C | 42.9 | 10.2 |
| 250°C | 46.3 | 12.1 |
| 200°C | 48.3 | 13.8 |
| 150°C | 50.3 | 15.8 |
| 100°C | 51.5 | 17.7 |
| 50°C | 51.7 | 19.5 |
Inconel 600 Flanges Standard and Country Origin
Inconel Steel Flange Stress Corrosion Cracking
Inconel Slip On Flanges Price List
1/2", FF, (SORF), SCH 40, Class 300
$13.96US $9.25 each
3/4", FF, (SORF), SCH 40, Class 300
$17.75US $13.35 each
1", FF, (SORF), SCH 40, Class 300
$20.56US $15.99 each
1-1/4", FF, (SORF), SCH 40, Class 300
$27.39 US $18.80 each
1-1/2", FF, (SORF), SCH 40, Class 300
$32.86 US $21.56 each
2", FF, (SORF), SCH 40, Class 300
$37.83 US $26.60 each
2-1/2", FF, (SORF), SCH 40, Class 300
$41.83 US $33.15 each
3", FF, (SORF), SCH 40, Class 300
$53.83 US $40.17 each
4", FF, (SORF), SCH 40, Class 300
$63.83 US $52.99 eachFor Final Inconel 625 Blind Flange Price List Please Drop an Email to sales@shikharsteel.com
Top Applications of Inconel Blind Flange
Suitable Acids for Inconel 718 Flanges
Top 5 Most Used Face Types Of Alloy 625 Flange
Is Inconel Flanges Stronger Than Stainless Steel?
Yes, Inconel 625 flanges are usually stronger than stainless steel flanges
We have more than 12 years of experience as an Inconel flanges manufacturer, Supplying Inconel 718 WNRF flange that are stocked or available in custom sizes and wall thickness as per ASME B16.5. ASTM B564 UNS N06625 flange handling corrosive and high temperature gases and fluids.
Types of Inconel Pipe Flange for Chemical Processing
Inconel Blind Flange
Inconel Alloy Weld Neck Flange
Inconel 600 Slip On Flange
Inconel 601 Socket Weld Flange
Inconel 625 Lap Joint Flange
Inconel 718 Plate Flanges
Alloy 625 Long Neck Flanges
Nickel Alloy 600 Threaded Flange
ASTM B564 UNS N06600 Orifice Flange
ASME SB564 UNS N06625 Spectacle Blind Flanges
Nickel 718 Alloy Reducing Flange
WNR 2.4856 Puddle Flanges
Weights of Inconel 625 Weld Neck Flanges
| NPS | Class 300 Inconel WNRF Flanges | Class 150 Inconel Weld Neck Flange |
|---|---|---|
| 24 | 261 | 120.6 |
| 22 | 209.3 | 101.3 |
| 20 | 180 | 88.7 |
| 18 | 144 | 74.3 |
| 16 | 112.5 | 63 |
| 14 | 92.7 | 51.3 |
| 12 | 63.9 | 39.6 |
| 10 | 45 | 24.3 |
| 8 | 31.1 | 18.9 |
| 6 | 20.3 | 11.7 |
| 5 | 16.2 | 9.5 |
| 4 | 11.9 | 7.4 |
| 3½ | 9 | 5.4 |
| 3 | 8.1 | 5.2 |
| 2½ | 5.4 | 4.5 |
| 2 | 4.1 | 2.7 |
| 1½ | 3.2 | 1.8 |
| 1¼ | 2.3 | 1.4 |
| 1 | 1.8 | 1.4 |
| 3/4 | 1.4 | 0.9 |
| 1/2 | 0.9 | 0.9 |
Advantages of ASTM B564 UNS N06600 Flange
How Do ASTM B564 N06625 Handle High Temperatures?
Inconel 625 flanges have unique composition like chromium, iron and nickel suitable for high temperature capabilities.
Inconel flanges manufacturer in forging and CNC machining. Inconel 718 SWRF flanges is a excellent corrosion resistance and non magnetic. Inconel forged flange are commonly used in chemical industries, marine and oil and gas applications.
Inconel Forgings Flange Manufacturing Process
Raw Material
Chemical Testing
Material Cutting
Forging
Heat Treatment
Forging Rolling
Inspection
Surface Finish
Packaging
Can Nickel 601 Socket Weld Flange Be Welded?
Yes, Inconel 601 socket weld flange are weldable using standard methods like GTAW, GMAW, and SAW welding.
Leading Inconel flanges Manufacturer in India, known for producing high performance Inconel 625 flanges designed for extreme temperatures. ASTM B564 UNS N06600 Flange is a nickel chromium alloy with oxidation resistance and good carburization through 2000°F. ASTM B564 UNS N06601 Flange is highly resistant to oxidation through 2200°F.
Suitable Temperature for Inconel Hot Forged Flange
What is the Strongest Inconel Forged Flange?
Almost all Inconel flange grades strongest, But Inconel 718 flange is more strongest due to excellent tensile and age-hardening capabilities.
ASTM B564 Flange Corrosion Tests
| Grade | Inconel 600 Flanges |
|---|---|
| Temperature | 932°F to 1112°F |
| Test Duration | 36 Hours |
| Tests | Hydrogen Fluoride Gas |
| Corrosion Rate | 0.7 mpy |
Inconel Steel Flange Tensile Strength
| Grades | Tensile Strength |
|---|---|
| Inconel 600 Flange | 655 MPa |
| Inconel 601 Flange | 550 MPa |
| Inconel 625 Flange | 930 MPa |
| Inconel 718 Flange | 930 MPa |
Inconel Weld Flange Yield Requirements
| Grades | Yield Strength (0.2%Offset) |
|---|---|
| ASTM B564 UNS N06600 | 45,000 Psi |
| ASTM B564 UNS N06601 | 30,000 Psi |
| ASTM B564 UNS N06625 | 75,000 Psi |
| ASTM B564 UNS N07718 | 75,000 Psi |
Inconel Flanges Equivalent
UNS (North America)
JIS (Japan)
EN (Europe)
AFNOR (France)
BS (England)
WNR (Russia)
Inconel Forgings Flange Chemical Composition
C
Carbon
600 = 0.15
601 = 0.10
625 = 0.10
718 = 0.08
S
Sulphur
600 = 0.015
601 = 0.015
625 = 0.015
718 = 0.015
Ni
Nickel
600 = 72.0
601 = 58.0 to 63.0
625 = 58.0
718 = 50 to 55
Si
Silicon
600 = 0.50
601 = 0.50
625 = 0.50
718 = 0.35
Mn
Manganese
600 = 1.0
601 = 1.0
625 = 0.50
718 = 0.35
Cu
Copper
600 = 0.5
601 = 1.0
718 = 0.3
Fe
Iron
600 = 6.0 to 10.0
601 = Balance
625 = 5.0
Cr
Chromium
600 = 14.0 - 17.0
601 = 21.0 – 25.0
625 = 20.0 - 23.0
718 = 17 - 21
Mo
Molybdenum
601 = 8.0-10.0
718 = 2.8 - 3.3
Al
Aluminum
601 = 1.0 – 1.7
Co
Cobalt
718 = 1.0 max
Inconel Pipe Flange Mechanical Properties
Density
Melting Point
Elongation
